Concluding steps
▶
Dispose of the CMOS battery in accordance with local regulations
concerning special waste.
▶
"Installing the air duct" on page
79.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
Verify that the iRMC displays voltage sensor information (BATT 3.0 V).
▶
If applicable, "Installing the front cover with lock" on page 71.
▶
BIOS settings are automatically reloaded. Time and date must be set
manually, see "Verifying the system time settings" on page 104.
17.4 Trusted Platform Module (TPM)
17.4.1 TPM kit
Figure 333: TPM installation kit
1 TPM
2
TPM spacer
3 Special screw for TPM
4 TPM bit insert for TPM special screw
System board and components
492 Upgrade and Maintenance Manual RX2540 M7
