Fujitsu PRIMERGY RX2540 M7

Parts of the LC kit
Figure 230: LC kit
1 LC heat sink with pump for CPU 1
2
Cable clips
3 Tubes
4 Quick connector block
5 LC heat sink with pump for CPU 2
12.3 Replacing the CPU for LC device
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screwdriver
–
Torx 30 screwdriver
Liquid cooling (LC)
376 Upgrade and Maintenance Manual RX2540 M7
