18.2.3.4 Indicator on hot-plug PSU
Figure 368: PSU status indicator (AC PSU)
Figure 369: PSU status indicator (DC PSU)
1 PSU status indicator
PSU status indicator (1)
Status Description
flashing green The server is switched off, but mains voltage is present
(standby mode).
green on The server is switched on and operating properly.
Appendix A
RX2540 M7 Upgrade and Maintenance Manual 553
