15.4 Front VGA
15.4.1
Installing the front VGA
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
hexagon screw driver 5 mm (for front VGA)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
If applicable, "Removing the riser module 1" on page 72.
▶
"Removing the fan cage" on page 76.
▶
"Removing the air duct" on page 80.
Front panel
470 Upgrade and Maintenance Manual RX2540 M7
