M.2 SSD slot BIOS menu iRMC SEL
1 M.2 SSD1 Port 4 Port 4
2 M.2 SSD2 Port 6 Port 6
7.8.2 Installing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Checking boot priority" on page 93.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
Installing the M.2 SSD
To support different length of M.2 SSD, the M.2 SSD latch can be
moved to another position.
Hard disk drive (HDD) / solid state disk (SSD)
212 Upgrade and Maintenance Manual RX2540 M7
