K - Fans
Status Description
off System fan running
orange on System fan failure
L - Battery
Status Description
orange on Battery failure
18.2.2 Server front
18.2.2.1
Connectors on the server front
Figure 359: Connectors on the server front
1 USB 3.0 connector
2
USB 3.0 connector
3 Front VGA connector (option)
Appendix A
RX2540 M7 Upgrade and Maintenance Manual 537
