Fujitsu PRIMERGY RX2540 M7

4.12 Handling the air duct
4.12.1
Installing the air duct
Installing the air duct
Figure 32: Installing the air duct
▶
Install the air duct.
Ensure that the air duct engages in the guiding points (see circles).
▶
If applicable, install all riser modules, see "Handling riser modules" on
page
72.
Basic hardware procedures
RX2540 M7 Upgrade and Maintenance Manual 79
