Concluding steps
▶
"Installing the air duct" on page
79.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
When the system is powered on after a CPU has been replaced or
upgraded, the Global Error indicator will start flashing with the message
CPU has been changed.
This only indicates that the CPU configuration has been altered. There
is no technical problem.
Proceed as follows:
●
Restart your server
.
●
As soon as the startup screen appears, press the [F2] function key to
enter the BIOS.
●
If a password is assigned, enter the password and press [Enter].
●
Select the Exit menu.
●
Select Commit settings and Exit.
●
Verify that the Global Error indicator stops flashing.
▶
"Resuming BitLocker functionality" on page
107.
11.4 Handling the CPU dummy cover
CPU dummy cover overview
The CPU dummy cover is used in specific configurations to prevent any
unexpected thermal conditions. It is not installed in the system as
standard.
If you add or remove a CPU dummy cover, use the Chassis ID Prom
Tool to update the system information.
Processor (CPU)
362 Upgrade and Maintenance Manual RX2540 M7

Fujitsu PRIMERGY RX2540 M7 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors
Storage	Up to 24 x 2.5-inch drives or 12 x 3.5-inch drives
RAID	Integrated RAID controller with support for RAID 0/1/5/6/10/50/60
Network	optional 10/25GbE
Power Supply	Redundant power supplies; 800W, 1300W, or 1600W
Expansion Slots	Up to 8 x PCIe slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
