15.4.3 Replacing the front VGA
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screwdriver (for cover 2)
–
hexagon screwdriver 5 mm (for front VGA)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
If applicable, "Removing the riser module 1" on page 72.
▶
"Removing the fan cage" on page 76.
▶
"Removing the air duct" on page 80.
Removing the defective front VGA
▶
Remove the front VGA, see "Removing the front VGA " on page 473.
Installing the new front VGA
▶
Install the front VGA, see "Installing the front VGA" on page 470.
Concluding steps
▶
"Installing the air duct" on page 79.
▶
"Installing the fan cage" on page 77.
▶
If applicable, "Installing the riser module 1" on page 74.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
Front panel
476 Upgrade and Maintenance Manual RX2540 M7
