18.2.3.2 ID, CSS and Global Error indicators
Figure 366: ID, CSS and Global Error indicators
1 ID indicator
2
Global Error indicator
3 CSS indicator
ID indicator (1)
See also "iRMC-related status signals" on page
550.
Status Description
blue on The server has been highlighted using iRMC web interface
or the ID button on the front panel for easy identification.
flashing blue The server has been highlighted for easy identification
using the iRMC (A
VR) with disabled local VGA output.
Global Error indicator (2)
See also "iRMC-related status signals" on page
550.
Status Description
off No critical event detected (non-CSS component).
orange on Prefailure event detected (non-CSS component).
Appendix A
RX2540 M7 Upgrade and Maintenance Manual 549
