Example for iRMC S6 web interface display
Position Enclosure Slot
[0] 0
[1] 1
[2] 2
[3] 3
[4] 4
[5] 5
Information about HDD/SSD slots can also be displayed using the BIOS,
see "Displaying HDD/SSD slot information" on page
143.
7.9.2 Upgrading with rear HDD cage 1 and rear HDD
cage 2
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
CAUTION
All data on all HDDs in the array will be lost when deleting the RAID
array!
▶
Be sure to back up your data before deleting a RAID array.
▶
For more information, see the "iRMC S6 - Web Interface" user
guide.
After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom T
ool.
Preliminary steps
Hard disk drive (HDD) / solid state disk (SSD)
228 Upgrade and Maintenance Manual RX2540 M7
