Fujitsu PRIMERGY RX2540 M7 User Manual

9.5 OCP (Open Compute Project) modules
9.5.1
Position of the OCP module
Figure 142: Position of OCP module at the rear side
1 OCP module
There are different OCP modules available.
OCP modules can be equipped with SFP+ transceiver modules, see
"Handling SFP+ transceiver modules" on page
252.
9.5.2 Installing an OCP module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Expansion cards and backup units
262 Upgrade and Maintenance Manual RX2540 M7

Fujitsu PRIMERGY RX2540 M7 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors
Storage	Up to 24 x 2.5-inch drives or 12 x 3.5-inch drives
RAID	Integrated RAID controller with support for RAID 0/1/5/6/10/50/60
Network	optional 10/25GbE
Power Supply	Redundant power supplies; 800W, 1300W, or 1600W
Expansion Slots	Up to 8 x PCIe slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
