13.3.7 Replacing the ODD (3.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
Torx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
"Removing backup and optical disk media" on page 92.
▶
"Suspending BitLocker functionality" on page 89.
▶
"Checking boot priority" on page 93.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the fan cage" on page 76.
Removing the defective ODD
▶
Remove the ODD, see "Removing the ODD (3.5-inch chassis)" on
page 411.
Installing the new ODD
▶
Install the ODD, see "Installing the ODD (3.5-inch chassis)" on page 402.
Accessible drives
RX2540 M7 Upgrade and Maintenance Manual 419
