7.8.7 Replacing the M.2 interposer board
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the air duct" on page 80
▶
"Removing the fan cage" on page 76.
▶
If applicable, remove the riser module 2, see "Removing a riser module" on
page 72.
▶
If applicable, "Removing the SAS expander board holder" on page 208.
Removing the defective M.2 interposer board
▶
Remove the defective M.2 interposer board, see "Removing the M.2
interposer board" on page 222.
Installing the new M.2 interposer board
▶
Install the new M.2 interposer board, see "Installing the M.2 interposer
board" on page 219.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 225
