7.6.5 Installing 2.5-inch PCIe SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
If the PCIe SSD module is controlled by a RAID controller of the PRAID
EP5x0i family
, the PCIe SSD module can be installed during operation
(hot-plug), see "Installing a 2.5-inch HDD/SSD module" on page 179.
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
Locate the correct drive bay, see "Overview of configurations" on page 165.
▶
Depending on your operating system: "Shutting down the server" on
page 50.
Removing a 2.5-inch HDD/SSD dummy lock
In configuration with only one 8x 2.5-inch HDD backplane dummy locks
are installed to make it impossible to equip the bays with no HDD
backplane behind.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 185
