Connect the serial interface cable to the connector "Rear Serial" on the
system board (1).
▶
Insert the serial interface cable into the expansion card (2).
Concluding steps
▶
Install the riser module 2, see "Installing a riser module" on page
74.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
16.2.2 Removing the serial interface
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
● Phillips PH2 / (+) No. 2 screw driver (for cover 2)
●
Hexagon screw driver 5 mm
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
Remove the riser module 1, see "Removing a riser module" on page 72.
Additional interfaces
482 Upgrade and Maintenance Manual RX2540 M7
