System state Power-
on
indicator
ID
indicator
Time
l Active area BIOS boot check
continued
green on flashing
blue
About
3
minutes
m Active area BIOS boot check
completion
Recovery area BIOS restore
Attention: the Power-on
indicator is not green but is
reading the active area BIOS
and updating the recovery area.
white on flashing
blue
About
5 minutes
n Recovery area BIOS restore
completion
Record of the following
message on SEL.
BIOS TFTP or HTTP/HTTPS
flash OK (Recovery area)
white on blue off -
Section d, f, h and l: the time it takes depending on memory and the number of
PCI cards installed. The above is the result of actual measurement without
loading a PCI card with two 8G memory modules.
From section c on, user can connect to iRMC S6 web interface.
From section d onward, the screen will be displayed on the connected display
.
Please check the screen.
18.2.2.4 Indicator on the ODD
ODDs may have an indicator or not.
Appendix A
544 Upgrade and Maintenance Manual RX2540 M7
