Insert the riser card.
▶
Fasten the riser card with four screws (see circles).
▶
Install the GPU card, see "Installing a GPU card in a riser module" on
page
284.
Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 74.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
9.8 Internal RAID riser module
9.8.1 Installing an internal RAID riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page
89.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the fan cage" on page 76.
Expansion cards and backup units
RX2540 M7 Upgrade and Maintenance Manual 297
