Fujitsu PRIMERGY RX2540 M7

Position Enclosure Slot
16ch
HBA/
RAID (1)
Front
HDD
without
Expander
[16] 0
[17] 1
[18] 2
[19] 3
[20] 4
[21] 5
[22] 6
[23] 7
Rear
HDD
without
Expander
[0] 8
[1] 9
[2] 10
[3] 11
[4] 12
[5] 13
Table 11: iRMC S6 web interface display
Information about HDD/SSD slots can also be displayed using the BIOS,
see "Displaying HDD/SSD slot information" on page 143.
7.6.1.3 Configuration with up to 24 PCIe SSD modules
Figure 77: Configuration with up to 24x 2.5-inch PCIe SSDs
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 173
