Installing additional HDD/SSD/PCIe SSD modules
▶
Insert additional HDD/SSD modules, see "Installing 2.5-inch HDD/SSD
modules" on page
177 or PCIe SSD modules, see "Installing 2.5-inch PCIe
SSD modules" on page 185.
Concluding steps
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 113. Select the
corresponding system name.
▶
"Performing a RAID array rebuild" on page 108.
7.9.4 Replacing a rear 2x 2.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
Hard disk drive (HDD) / solid state disk (SSD)
236 Upgrade and Maintenance Manual RX2540 M7
