Figure 57: Installing the 2.5-inch HDD/SSD in the 3.5-inch installation frame (B)
▶
Fasten the 2.5-inch HDD/SSD with four screws.
Removing a 2.5-inch HDD/SSD from a 3.5-inch installation frame
▶
Please proceed in reversed order
.
Concluding steps
No steps needed.
7.4 Displaying HDD/SSD slot information
Information about HDD/SSD slots can be displayed using the BIOS or the
iRMC S6 web interface.
The display depends on the installed expansion cards, the HDD
backplanes and the cabling.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 143
