9.7 GPU cards in riser modules
9.7.1
Installing a GPU card in a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver 4.5 mm
Preliminary steps
▶
"Suspending BitLocker functionality" on page
89.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
Remove all riser modules, see "Removing a riser module" on page 72.
▶
If no riser module is installed: Remove the corresponding rear air grid, see
"Removing a rear air grid" on page 85.
▶
"Removing the air duct" on page 80.
▶
"Removing the crossbar" on page 83.
Installing the GPU card in a riser module (example GPU NVIDIA A16)
The GPU cards A30/A40/A100/H100/RTX A4500/RTX A6000/A30X/
A100X have the same installation procedure.
Expansion cards and backup units
284 Upgrade and Maintenance Manual RX2540 M7
