Figure 88: Installing the 2.5-inch HDD/SSD dummy module
▶
Push the dummy module into the empty bay until it engages.
▶
If applicable, insert the dummy lock.
Concluding steps
▶
If applicable, "Switching on the server" on page
71.
▶
If applicable, "Installing the front cover with lock" on page 71.
7.6.7 Replacing a 2.5-inch PCIe SSD module
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: – Installation frame included: tool-less
–
Installation frame excluded: Phillips PH1 / (+) No. 1 screw driver
Hard disk drive (HDD) / solid state disk (SSD)
