Figure 361: Indicator on the ODD (example)
1 Activity indicator
Activity indicator (1)
Status Description
off The ODD is inactive.
green on The storage medium is being accessed.
18.2.2.5 Indicators on the RDX drive
Figure 362: Indicators on the RDX drive
1 RDX drive Power-on indicator
Appendix A
RX2540 M7 Upgrade and Maintenance Manual 545
