Installing the new 2.5-inch PCIe SSD module
▶
Install the PCIe SSD module, see "Installing 2.5-inch PCIe SSD modules"
on page 185.
Concluding steps
▶
If applicable, "Switching on the server" on page
71.
▶
Verify that the operating system recognizes the newly installed drive.
▶
If applicable, "Installing the front cover with lock" on page 71.
7.6.8 Replacing a 8x 2.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
In configuration with 24x 2.5-inch HDD/SSD/PCIe modules the third
backplane is a combo HDD backplane that also allows to install PCIes.
The replacing procedure is the same as a HDD backplane.
There are three types of 8x 2.5-inch HDD backplane (P/N: CA05973-8303)
with or without a foam.
Hard disk drive (HDD) / solid state disk (SSD)
192 Upgrade and Maintenance Manual RX2540 M7
