"Switching on the server" on page
71.
▶
If applicable, "Installing the front cover with lock" on page 71.
17.5.3 Removing the iRMC microSD card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screwdriver (for cover 2)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
If applicable, remove the expansion card from slot 5 and slot 6, see
"Removing an expansion card" on page 278.
Removing the iRMC microSD card
Figure 343: Removing the iRMC microSD card
System board and components
506 Upgrade and Maintenance Manual RX2540 M7
