15.3 Common operation panel (COP)
15.3.1
Replacing the COP
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
Phillips PH1 / (+) No. 1 screw driver (for COP)
Note on system information backup/restore
The COP contains the Chassis ID EPROM that contains system information
like server name and model, housing type, serial number and manufacturing
data. T
o avoid the loss of non-default settings when replacing the system
board, a backup copy of important system configuration data is automatically
stored from the system board NVRAM to the Chassis ID EPROM.
CAUTION
For that reason the COP and the system board should not be replaced
simultaneously! In this case, the automatically restoring of the system
configuration data on the system board would fail.
▶
If the COP and the system board are replaced at the same time,
reconfigure the BIOS/iRMC and restore the system information like
server name, server model, housing type, serial number and
manufacturing data manually by Chassis ID Prom T
ool.
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the fan cage" on page 76.
Front panel
464 Upgrade and Maintenance Manual RX2540 M7
