7.5.5 Replacing the 10x 3.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the fan cage" on page 76.
▶
Release all HDD modules and pull them out a few centimeters, see
"Removing 3.5-inch HDD modules" on page 153.
CAUTION
The HDD modules need not to be removed.
▶
If you want to remove them nevertheless, check if all HDD
modules are uniquely identified so that you can reinsert them
into their original bays.
▶
Release all dummy modules and pull them out a few centimeters, see
"Removing a 3.5-inch HDD dummy module" on page
151.
Removing the defective 10x 3.5-inch HDD backplane
▶
If applicable, remove the internal RAID riser module, see "Removing an
internal RAID riser module" on page 303.
▶
Disconnect all cables from the HDD backplane.
Hard disk drive (HDD) / solid state disk (SSD)
158 Upgrade and Maintenance Manual RX2540 M7
