CAUTION
Incorrect cabling may cause wrong LED identification of the HDD/SSD.
Misleading LED could lead to swapping out the wrong HDD/SSD, and
that will result in data loss.
▶
Check the correct cabling using the labels on the cables and the
cable plans.
Concluding steps
▶
"Installing the fan cage" on page
77.
▶
"Reassembling" on page 59.
▶
Insert all PCIe SSD modules, see "Installing a 2.5-inch HDD/SSD module"
on page 179.
Ensure that you install the PCIe SSD module in the bay it was located
before the HDD backplane replacement.
▶
Insert all dummy modules, see "Installing a 2.5-inch HDD/SSD dummy
module" on page
182.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
Verify that the iRMC S6 recognizes the installed HDDs/SSDs.
▶
If applicable, "Installing the front cover with lock" on page 71.
7.7 SAS expander board
7.7.1 Installing the SAS expander board
The SAS expander board is an option for the 12x 3.5-inch HDD
configuration, the 16x 2.5-inch HDD/SSD configuration and the 24x 2.5-
inch HDD/SSD configuration.
