9.5.3 Removing an OCP module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page
50.
▶
"Disconnecting the power cord" on page 50.
Removing the OCP module
Figure 145: Removing the OCP module
▶
Loosen the knurled screw (see circle).
▶
Remove the OCP module.
Expansion cards and backup units
RX2540 M7 Upgrade and Maintenance Manual 265
