9.7.4 Replacing a riser card
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Locating the defective component" on page 48.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 72.
Removing the defective riser card
▶
Remove the GPU card, see "Removing a GPU card from a riser module" on
page 290.
Expansion cards and backup units
RX2540 M7 Upgrade and Maintenance Manual 295
