Concluding steps
▶
If applicable, install the corresponding riser module, see "Installing a riser
module" on page
74.
▶
If applicable, install the corresponding rear air grid, see "Installing a rear air
grid" on page 87.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
▶
If applicable, update the system information of your server using the Chassis
ID Prom Tool, see "Using the Chassis ID Prom Tool" on page 113.
▶
"Resuming BitLocker functionality" on page 107.
9.9.3 Replacing expansion cards from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screwdriver
Note on network settings recovery
When replacing network controllers, network configuration settings in
the OS will be lost and replaced by default values. This applies to all
static IP address and LAN teaming configurations.
Ensure to note down your current network settings before replacing a
network controller
.
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
Expansion cards and backup units
RX2540 M7 Upgrade and Maintenance Manual 315
