Lay the 2.5-inch HDD/SSD into the 2.5-inch installation frame as shown.
Figure 55: Installing the 2.5-inch HDD/SSD in the 2.5-inch installation frame (B)
▶
Fasten the 2.5-inch HDD/SSD with four screws.
Removing a 2.5-inch HDD/SSD from a 2.5-inch installation frame
▶
Please proceed in reversed order
.
Concluding steps
No steps needed.
7.3.3 2.5-inch HDD/SSD and 3.5-inch installation frame
Installing or removing the installation frame is only necessary for Japan.
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Hard disk drive (HDD) / solid state disk (SSD)
