Installing a hot-plug PSU
Figure 47: Installing a hot-pug PSU
▶
Push the PSU into its bay as far as it will go (1) until the release latch (A)
snaps in place.
▶
Fold down the handle on the PSU (2).
Ensure that the PSU engages correctly in the bay and is locked in
position.
Power supply unit (PSU)
128 Upgrade and Maintenance Manual RX2540 M7
