Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the fan cage" on page 76.
Removing the defective SAS expander board
▶
Disconnect all cables from the SAS expander board.
▶
Remove the SAS expander board, see "Removing the SAS expander
board" on page 207.
Installing the new SAS expander board
▶
Install the SAS expander board, see "Installing the SAS expander board" on
page 202.
▶
Connect the cables to the SAS expander board, see Figure 103.
Concluding steps
▶
"Installing the fan cage" on page 77.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
Verify that the iRMC S6 recognizes the installed HDDs/SSDs.
Hard disk drive (HDD) / solid state disk (SSD)
