Removing the M.2 SSD
Figure 109: Removing the M.2 SSD (A)
▶
Push the green latch in direction of the arrow
.
Figure 110: Removing the M.2 SSD (B)
▶
T
ake the M.2 SSD out of its slot at a slight angle.
▶
If applicable, remove the second M.2 SSD in the same way.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 217
