Installing the fan module
Figure 126: Installing the fan module
▶
Insert the fan module in the fan cage.
▶
Press down the fan module until it locks.
Concluding steps
▶
"Reassembling" on page
59.
▶
If applicable, "Installing the front cover with lock" on page 71.
▶
Check the CSS indicator and Global Error indicator and ensure that they are
off.
▶
"Performing a fan test" on page 117.
A fan test does not need to be performed if the fan module is actively
replaced. iRMC runs automatically.
Fans
244 Upgrade and Maintenance Manual RX2540 M7
