Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
Torx 30 screw driver (for CPU heat sink)
CAUTION
CPUs are extremely sensitive to electrostatic discharge and therefore
must always be handled with care.
▶
After a CPU has been removed from its protective sleeve or from its
socket, place it upside down on a nonconducting, antistatic surface.
▶
Never push a CPU over a surface.
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
"Suspending BitLocker functionality" on page 89.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
"Removing the air duct" on page 80.
Processor (CPU)
366 Upgrade and Maintenance Manual RX2540 M7
