Pos. Print Description
1 Rear VGA Rear VGA connector
2 Front VGA Rear VGA connector
3 PSU 1 Power supply connector hot-plug PSU 1
4 PWR 7 Power connector 7
5 HDD LED 3 LED activity connector 3
6 PWR 6 Power connector 6
7 FRONT PANEL Front panel connector
8 SMB 2
9 PWR 5 Power connector 5
10 PWR 4 Power connector 4
11 FAN6_SYS Power connector for system fan 6
12 FAN5_SYS Power connector for system fan 5
13 FAN4_SYS Power connector for system fan 4
14 PWR M2 Power connector for M.2 interposer board
15 PWR 3 Power connector 3
16 PWR 2 Power connector 2
17 FAN3_SYS Power connector for system fan 3
18 FAN2_SYS Power connector for system fan 2
19 FAN1_SYS Power connector for system fan 1
20 Thermal sensor Thermal sensor connector
21 PWR ODD ODD power connector
22 PWR 1 Power connector 1
23 SATA 4-7 SATA HDD connector
24 USB 3.0 USB 3.0 connector (internal)
25 INTERPOSER 1 M.2 interposer board connector
26 PWR 8 Power connector 8
27 PSU 2 Power supply connector hot-plug PSU 2
Appendix A
RX2540 M7 Upgrade and Maintenance Manual 533
