GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
8-12 Section 8-3 - System Software - Installation/Upgrade Procedure
8-3-5-2-1-4 Connectivity - Recording the AE Title and Port settings
1) From the touch panel, select Utility -> Connectivity -> Device.
2) Select My Computer in the List of Devices, if not already selected.
Figure 8-3 Connectivity - Recording the AE Title and Port settings (R1.x.x)
Figure 8-4 Connectivity - Recording the AE Title and Port settings (R2.x.x and later)
3) Record all settings in Table 8-6.
Table 8-6 Record settings for My Computer from Device screen
Parameter Value
AE Title
Port Number
MAC Address (R1.x.x)
To Next Page
