8-22 Section 8-3 - System Software - Installation/Upgrade Procedure

8-3-5-2-1-14 System - Recording Peripheral settings

1) From the touch panel, select Utility -> System-> Peripherals.

Figure 8-14 System - Recording Peripheral settings (R1.x.x.)

Figure 8-15 System - Recording Peripheral settings (R2.x.x. and later)

2) Record all settings in Table 8-18.

Table 8-18 Record settings from Peripherals screen (R1.x.x)

Parameter Value

Video Settings - Format

Standard Printer

Default Printer

Setup - Print Full Screen

Setup - Enable Video Invert

DVR Picture Quality

Main Page
