8-84 Section 8-14 - Replacement of OPIO and Related Parts

2) Remove 2 screws on OPIO covers.

Figure 8-76 Rear of OPIO Base

3) Remove USB cables on Touch panel and unscrew 2 screws. Refer to following figure.

Figure 8-77 USB cable position and screw points.

USB connector

Screw points
