130 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
E3 Series System Connections PM-9/PM-9G Power Supply Connections
3.8.2 PM-9/PM-9GBattery Connections
• Two (2), twelve volt batteries are connected in series to the PM-9/PM-9G.
• TB3-1 is positive. (For PM-9, see Table 3.8.5.1 and for PM-9G, see Table 3.8.8.1)
• TB3-2 is negative. (For PM-9, see Table 3.8.5.1 and for PM-9G, see Table 3.8.8.1)
• 14 AWG wire minimum
• Observe polarity
See Table 3.15.1 for the Battery Calculations.
3.8.3 PM-9 and PM-9G Specifications
3.8.3.1 PM-9/PM-9G
The following list the electrical specifications for the PM-9 and PM-9G.
Specifications PM-9 PM-9G
Input Voltage: 120 VAC, 60 Hz 240VAC @ 50/60 Hz
Input Current: 4.6 amps max. @ 120 VAC 60 Hz 2.4 amps max.
Output Voltage: 24 VDC FWR 24 VDC FWR
Output Current: 9 amperes Alarm max. continuous 9 amperes Alarm max. continuous
Output Current: 5 amperes max. continuous
Standby (when the PM-9 is used
with the ILI-E3 or the ILI95-E3
Series) (See Note 1)
5 amperes max. continuous Standby
(when the PM-9G is used with the
ILI-E3 or the ILI95-E3 Series)
(See Note 1)
Output Current: 4 amperes max. continuous
Standby (when the PM-9 is used
with any AM-50 Series amplifier)
(See Note 2)
4 amperes max. continuous Standby
(when the PM-9G is used with any
AM-50 Series amplifier)
(See Note 2)
Operating Temperature: 32° to 120° F (0° to 49° C) 32° to 120° F (0° to 49° C)
Relative Humidity: 0 to 93%, non-condensing at 90° F
(32° C)
0 to 93%, non-condensing at 90° F
(32° C)
Supervised
Non Power-Limited
NOTE 1: Continuous standby loads in excess of .560 Amps up to 5 Amps may require a
Generator Backup or load shedding during an AC power failure. See Section 3.15 Standby
Battery Calculations in this Manual.
NOTE 2: Continuous standby loads in excess of .560 Amps up to 4 Amps may require a
Generator Backup or load shedding during an AC power failure. See Section 3.15 Standby
Battery Calculations in this Manual.
