Digital Alarm Communicator Transmitter (DACT-E3) Connections E3 Series System Connections
3.10.5 DACT-E3 Event Reporting Codes
The DACT-E3 can be configured to allow each SLC device to report a unique 3-digit code by
selecting the Extended DACT Reporting Feature. To enable this feature, each ILI-MB-E3 and ILI-
S-E3 must have V1.3 of the ILI Firmware installed. This feature is also available for the ILI95-MB-
E3 and ILI95-S-E3.
The Extended DACT Reporting Feature is disabled by default. The user must specifically enable
this feature through configuration programming using CAMWorks™. If this feature is disabled, use
the standard codes (enclosed in the brackets in Table 3.10.5.1). If this feature is enabled, the
optional fields, (enclosed in the parentheses in Table 3.10.5.1) will be substituted for the standard
codes. For additional information regarding this feature, see Notes 4 and Note 5 in Table 3.10.5.1.
NOTE: To use the Extended DACT Reporting Feature, all ILI-MB-E3 and ILI-S-E3 nodes on the
network must have V1.3 Firmware installed.
Event
SIA
(See Note 2) Contact ID
4/2
3/1
Fire Alarm (Smoke or Manual Station) FA [GGT] (UUU) 1 110 [00] (NN) [GGT] (UUU) 0 [T] (U) 0
Fire Alarm Restored FH [GGT] (UUU) 3 110 [00] (NN) [GGT] (UUU) 2 [T] (U) 2
Waterflow Alarm SA [GGT] (UUU) 1 113 [00] (NN) [GGT] (UUU) 0 [T] (U) 0
Waterflow Alarm Restored SH [GGT] (UUU) 3 113 [00] (NN) [GGT] (UUU) 2 [T] (U) 2
Trouble (except Waterflow or Special AMM/PID) FT [GGT] (UUU) 1 373 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Trouble Restored FJ [GGT] (UUU) 3 373 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
Trouble (Waterflow AMM/PID) ST [GGT] (UUU) 1 370 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Trouble Restored (Waterflow AMM/PID) SJ [GGT] (UUU) 3 203 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
Trouble (Special AMM/PID) UT [GGT] (UUU) 1 370 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Trouble Restored (Special AMM/PID) UJ [GGT] (UUU) 3 370 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
Supervisory / Tamper (Module) SS [GGT] (UUU) 1 203 [00] (NN) [GGT] (UUU) 6 [T] (U) 6
Supervisory Restored (Module) SR [GGT] (UUU) 3 203 [00] (NN) [GGT] (UUU) 7 [T] (U) 7
PAS/Action/Supervisory (Sensor) FS [GGT] (UUU) 1 200 [00] (NN) [GGT] (UUU) 6 [T] (U) 6
PAS/Action/Supervisory Restored (Sensor) FR [GGT] (UUU) 3 110 [00] (NN) [GGT] (UUU) 7 [T] (U) 7
Disable (except Waterflow or Special AMM/PID) FB [GGT] (UUU) 1 571 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Disable Restored FU [GGT] (UUU) 3 571 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
Disable (Waterflow AMM/PID) SB [GGT] (UUU) 1 570 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Disable Restored (Waterflow AMM/PID) SU [GGT] (UUU) 3 570 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
Disable (Special AMM/PID) UB [GGT] (UUU) 1 570 [00] (NN) [GG0] (UUU) 8 [T] (U) 8
Disable Restored (Special AMM/PID) UU [GGT] (UUU) 3 570 [00] (NN) [GG0] (UUU) 7 [T] (U) 7
AC Fail AT 0 1 301 [00] (NN) [000] (UUU) 8 [T] (U) 8
AC Fail Restored AR 0 3 301 [00] (NN) [000] (UUU) 7 [T] (U) 7
Phone Line 1 Fault LT 1 1 351 [00] (NN) [000] (UUU) 81 8
Phone Line 1 Fault Restored LR 1 3 351 [00] (NN) [000] (UUU) 71 7
Phone Line 2 Fault LT 2 1 352 [00] (NN) [000] (UUU) 82 8
