Honeywell Gamewell-FCI E3 Series - 3.11.6 RPT-E3 Wiring Diagram

E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 157
Repeater (RPT-E3) Connections E3 Series System Connections
3.11.6 RPT-E3 Wiring Diagram
Figure 3.11.6.1 illustrates the field wiring connections for the RPT-E3.
Figure 3.11.6.1 RPT-E3 Wiring Diagram
TX
PWR
D18
J5
J6
J4
J9
J8
D10
RX1
D11
D12
RX2
ARCNET
16
15
J7
LEAVE OPEN
TERM
COM B IN
COM A IN
GND(-) OUT TO NGA TB1-2
+24VDC OUT TO NGA TB1-1




ARCNET PORT 2B
ARCNET PORT 2A
ARCNET PORT 1A
ARCNET PORT 1B
SHORTED
1
1
TB1
32 4
TB4
4
1
21 3
1
TB3
1 2 3
TB2
J3
J10
2
1
4
J1
COM B OUT TO NGA TB1-4
ARCNET
COM A OUT TO NGA TB1-3
J10 CONNECT TO LOCAL
ILI-MB-E3, ILI95-MB-E3 OR
ANX J4 ARCNET CONNECTOR
(NOTE PIN 1 POSITION)
CONNECT TO EARTH GROUND AND
ENABLE GROUND DETECTION WHEN
REMOTELY MOUNTED
(NOTE: NOT APPLICABLE WHEN USING
FIBER-OPTIC CONNECTIONS)
ARCNET
LOCAL DIFFERENTIAL
TB4 HARD-WIRED POWER
CONNECTIONS NOT
REQUIRED WHEN J10 USED
U5
(RX2)
U7
(TX2)
U4
(RX1)
U6
(TX1)
LEDS
D12 ON = RECEIVING NETWORK TRANSMISSIONS INTO ARCNET PORT 2 OR U5
OFF OR BLINKING = NOT RECEIVING NETWORK TRANSMISSIONS INTO ARCNET PORT 2 OR U5
D11 ON = RECEIVING NETWORK TRANSMISSIONS INTO ARCNET PORT 1 OR U4
OFF OR BLINKING = NOT RECEIVING NETWORK TRANSMISSIONS INTO ARCNET PORT 1 OR U4
D10 ON = TRANSMITTING TO NETWORK
OFF = NOT TRANSMITTING TO NETWORK
D18 ON = POWERED
OFF = NOT POWERED
J2 SHORT TO
ENABLE
GROUND FAULT
DETECTION
NOTE: SEE RPT-E3 WIRING
CONNECTIONS AND
TRANSMITTER OUTPUT
SETTINGS TABLES.
J2
GFI
FROM PREVIOUS NODE
TX1 CONNECTOR
FROM PREVIOUS NODE
RX1 CONNECTOR
TO NEXT NODE
TX2 CONNECTOR
TO NEXT NODE
RX2 CONNECTOR
NOTE: 2-PIN SHUNT
PLACED OVER PINS
OPEN
