Honeywell Gamewell-FCI E3 Series - Cabinet C, E3-INX-C Plate, Outer Door Installation

62 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
Installation Cabinets
2.5.8.3 Cabinet C, E3-INX-C Plate, Outer Door Installation
Mount the E3-INX C Plate outer door to the backbox, by securing four (4), #6-32 nuts in the four-
hole mounting pattern on the left side of the backbox. See Locations 1, 2, 3, and 4 of the figure
below.
Figure 2.5.8.3.1 Cabinet C, E3-INX C Plate Outer Door Installation
N
U
T
,
H
E
X
,
#
6
-
3
2
4
P
L
A
C
E
S
CABINET C, INX E3
OUTER DOOR
CABINET C,
BACKBOX
1
2
3
4
