Honeywell Gamewell-FCI E3 Series User Manual

84 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
Installation Cabinets
2.5.10.3 Cabinet D, Outer Door Installation
1. Mount the door over the studs on the backbox.
2. Secure with four (4), #6-32 nuts in the four-hole mounting pattern on the left side of the
backbox. See Locations 1 thru 6 of the figure below.
Figure 2.5.10.3.1 Cabinet D, Outer Door Installation
CABINET D,
BACKBOX
CABINET D,
OUTER DOOR
N
U
T
,
H
E
X
,
#
6
-
3
2
6
P
L
A
C
E
S
1
2
3
4
5
6
