2.5.9.1 Cabinet C, E3-INCC-C Plate, Outer Door Installation
Mount the E3-INCC-C Plate outer door on the backbox, by securing four (4), #6-32 nuts in the
four-hole mounting pattern on the left side of the backbox. See Locations 1 thru 4 of the figure
below.
Figure 2.5.9.1.1 Cabinet C, E3-INCC-C Outer Door Installation
CABINET C, E3-INCC-C,
OUTER DOOR
