E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 165
LCD-E3 Panel Display Connections E3 Series System Connections
3.13.3 LCD-E3 Wiring Connections
Table 3.13.3.1 lists the field wiring connections for the LCD-E3.
Designation Description Comments
TB1-1 +24 +24V in from ILI-MB-E3 or ILI95-MB-E3 TB3-6
non-resettable B+
TB1-2 GND ILI-MB-E3 or ILI95-MB-E3 TB3-7
TB1-3 RS-485A RS-485A output from ILI-MB-E3 or ILI95-MB-E3
TB1-4 RS-485B RS-485B output from ILI-MB-E3 or ILI95-MB-E3
TB1-5 RS-485A RS-485A input from ILI-MB-E3 or ILI95-MB-E3
TB1-6 RS-485B RS-485B input from ILI-MB-E3 or ILI95-MB-E3
TB1-7 GND Connect to earth ground
TB1-8 Not used
J1 Local RS-485 Alternate RS-485 connection
J2 Keypad To keypad
J3 Display To display
J4 Factory use
W1 RS-485 Termination W1 should be CLOSED if it is the first or last device
on the RS-485 bus.
Otherwise, W1 should be OPEN.
W2 Keypad Keypad
IN = Disabling
OUT = Enabling
Table 3.13.3.1 LCD-E3 Wiring Connections
