Honeywell Gamewell-FCI E3 Series - 8: Cabinet C, E3-INX-C Plate Installation Instructions

E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 59
Cabinets Installation
2.5.8 Cabinet C, E3-INX-C Plate Installation Instructions
The Cabinet C Assembly typically houses the following:
• Backbox:
– Telephone Assembly - Two Batteries
– Microphone Assembly
– E3 Cabinet C, Trim Rings (Optional Accessory)
• E3-INX-C Plate Outer Door
• E3-INX-C Plate:
• Hardware Kit
Figure 2.5.8.1 Cabinet C, Standard View
– ILI-MB-E3/ILI95-MB-E3/ANX – PM-9/PM-9G
– DACT-E3 – INI-VG Series
– RPT-E3 – Up to a maximum of four (4), AM-50 Series
amplifiers (Optional)
